Electrcal Specifications |
|
|
Frequency Range |
698~960 / 1710-2700MHz |
|
Gain |
9dBi |
|
Polarization |
Vertical |
|
Horizontal Beam Width |
90° |
|
Vertical Beam Width |
60° |
|
Front to Back ratio |
≥18 dB |
|
VSWR |
≤1.5 |
|
Input impedance |
50 Ω |
|
Maximum Input power |
100 W |
|
Lightning Protection |
Direct Ground |
|
Mechanical Specifications |
|
|
Connector |
N-K |
|
Size |
300mm×210mm×65mm |
|
Weight |
1 kg |
|
Max Wind Speed |
60 m/s |
|
Diameter of Installation Pole |
φ55~φ105 |
|
Temperature |
-40℃~70℃ |
-------------------------------------------------------------------
